Crawler for pipeline JME 6:CR2
The JME 6:CR2 Pipeline Crawler is specifically designed for non-destructive testing of circumferential butt welds in tubular installations such as oil and gas transportation pipelines.
The second-generation CR2 range is the world's most technologically advanced NDT crawler system.
The JME 6:CR2 Pipeline Crawler is extremely compact and lightweight, deployable within an internal diameter range from 5.5" (140 mm) up to a maximum of 18" (457 mm). Paired with JME or ICM X-ray generators, this system enables high-quality single-wall single-image (SWSI) internal panoramic radiography.
The robot can be controlled using JME's magnetic control system (magnetope) or a conventional isotopic control system, with additional features accessible via our brand-new CR2 remote control.
Vidéo
Spécifications
Range of pipe diameters
5,5" à 18" (140 mm à 457 mm)
Weight (excluding X-ray tube)
battery 9Ah - 71lbs (32 Kg), battery 13Ah - 84lbs (38 Kg)
Length (not including X-ray tube)
1500mm (including recovery ring)
X-ray tube output options
JME CXT 180, ICM 160CR/1802S
Energy source
Sealed lead-acid batteries 48V (9Ah ou 13Ah)
Capacity of battery
9Ah / 13Ah Depending on pipe size requirements
Travel speed
Up to 12 metres (40 feet) per minute
Maximum angle of climb (optimum conditions)
25° from horizontal
Average positioning accuracy
±5 mm
Operating temperature range
-20°C à +70°C
X-RAY GENERATOR OPTIONS
JME CXT 180
ICM CP160CR
ICM C1802
